ÁRAMVÉDŐ KAPCSOLÓ JEL1 4P 20A/30MA

Technical characteristics:
- Rated current: 10-100 A
- Rated operating voltage: 230/400V; 50/60Hz
- Rated residual current: 30/100/300/500 mA
- Number of poles: 2/4
- Surge voltage wear resistance: ≥2000V
- Short circuit current wear resistance: 6000A
- IP code: IP>20
- Ambient temperature: -10°÷65º?
- Installation altitude: up to 2000m

Mounting: Vertical on a DIN rail

Standards: EN 61008-1; EN 61008-2; EN 60947-1
